The Back-UPS Pro provides abundant battery backup power, so you can work through medium and extended length power outages. It safeguards your equipment against damaging surges and spikes that travel along utility and data lines. The Back-UPS Pro also features automatic voltage regulation (AVR), which instantly adjusts high and low voltages to safe levels, so you can work indefinitely during brownouts and overvoltages. The Back-UPS Pro also includes unique “green” features, automatically turn off idle peripherals. A high efficiency charging system and “AVR Bypass” also reduce power consumption. With the rest of the Back-UPS Pro’s standard features, this is the perfect unit to protect your productivity from the constant threat of bad power and lost data. Key Features
Input Voltage – AC 230 V
Frequency Required – 50/60 Hz
Input Connector(s) – Power IEC 320 EN 60320 C14
Power Capacity – 865 Watt / 1500 VA
Remote Management Interface – RS-232, USB
Green mode Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. Battery failure notification Provides early-warning fault analysis on batteries enabling timely preventive maintenance Power-saving outlets Automatically cuts power to idle equipment to conserve electricity. Resettable circuit breaker Easy recovery from overloads; no need to replace a fuse. Extendable Run Time Additional batteries can be added to provide power to the load for an extended period of time in the event of utility supply failure. Battery-protected and surge-only outlets Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment Cold-start capable Provides temporary battery power when the utility power is out. Hot-swappable batteries Ensures clean, uninterrupted power to protected equipment while batteries are being replaced Disconnected battery notification Warns when a battery is not available to provide backup power. Dataline Surge Protection Provides protection of connected equipment from power surges on the data lines. Automatic self-test Periodic battery self-test ensures early detection of a battery that needs to be replaced. Adjustable voltage-transfer points Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation. Adjustable voltage sensitivity Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications. Audible alarms Provides notification of changing utility power and UPS power conditions User-replaceable batteries Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR) USB connectivity Provides management of the UPS via a USB port (not available on all models). Serial Connectivity Provides management of the UPS via a serial port. Transformer-block spaced outlets Protect equipment with input transformer blocks without blocking access to other receptacles. Boost and Trim Automatic Voltage Regulation (AVR) Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models). Intelligent battery management Maximizes battery performance, life, and reliability through intelligent, precision charging. Safety-agency approved Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment. Building Wiring Fault Indicator This LED informs users of potentially dangerous wiring problems in the wall circuit. Battery replacement without tools Enables fast battery replacement, lowering Mean Time to Repair (MTTR). LCD graphics display Text and mimic diagrams that display modes of operation, system parameters and alarms.
Please note: networking components such as switches, routers, UPS and wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on[email protected].
Technical Specification
APC Back-UPS Pro 865 Watt / 1500 VA LCD 230V
General
Width
11.2 cm
Depth
38.1 cm
Height
30.2 cm
Weight
13.4 kg
Enclosure Colour
Black
Output Connectors
10 x IEC connector
Device Type
UPS – external
Colour
Black
Power Device
Surge Suppression
Yes
Input Connector(s)
Power IEC 320 EN 60320 C14
Output Voltage
AC 230 V 50/60 Hz
Input Connectors
Power IEC 60320 C14
Power Output Connectors Details
5 x power IEC 60320 C13 (surge) ¦ 5 x power IEC 60320 C13 (UPS and surge)
Input Voltage
AC 230 V
Frequency Provided
50/60 Hz
Frequency Required
50/60 Hz
Power Capacity
865 Watt / 1500 VA
Dataline Surge Protection
Network – RJ-45 ¦ Phone line – RJ-11
Output Waveform
Stepped approximation to a sinewave
Manufacturer Warranty
Service & Support
Limited warranty – 2 years ¦ European Union: limited warranty – 3 years
Service & Support Details
Limited warranty – 2 years
Regional Warranty Exceptions
European Union – 3 years
Miscellaneous
Cables Included
Power cable – external – 1.8 m
Features
Audible alarm, LCD display, Automatic Voltage Regulation (AVR)
Compliant Standards
GOST, GS, NEMKO, RoHS
Battery
Quantity
1
Technology
Lead Acid
Networking
Remote Management Interface
RS-232, USB
Expansion / Connectivity
Interfaces
1 x management (RS-232/USB)
Software / System Requirements
Software Included
Drivers & Utilities, APC PowerChute Personal Edition
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Dimensions & Weight
Width
11.2 cm
Depth
38.1 cm
Height
30.2 cm
Weight
13.4 kg
Dimensions & Weight (Shipping)
Shipping Width
23.8 cm
Shipping Depth
48.9 cm
Shipping Height
38.2 cm
Shipping Weight
14.5 kg
